- Name: Electro graphite brush EG84 10x25x40 K8-2
- Brand: ZTV
- Product Code: ЕG84_10х25х40_K8-2
- Availability: Pre-order 39 calendar days
7.60€
Main specifications
All specifications
Material:
SL34
Analog material:
EG84
Сonstruction by ГОСТ Р 53617-2009:
К8-2
Сonstruction by IEC 60276:
CL06G
Conductor length by ГОСТ 12232-89, no less, L :
100 mm
Conductor cross-section, S :
2,5 mm²
Conductor insulation :
present
Terminal type according to ГОСТ Р 53617-2009:
5B
Cover type according to ГОСТ Р 53617-2009:
missing
Terms of agreement
All goods are certified
Privacy Policy
We accept payment online
Electro graphite brush EG84 10x25x40 K8-2 for motors and generators
Specifications
Main characteristics
Material
SL34
Analog material
EG84
Сonstruction by ГОСТ Р 53617-2009
К8-2
Сonstruction by IEC 60276
CL06G
Conductor length by ГОСТ 12232-89, no less, L
100 mm
Conductor cross-section, S
2,5 mm²
Conductor insulation
present
Terminal type according to ГОСТ Р 53617-2009
5B
Cover type according to ГОСТ Р 53617-2009
missing
Additional parameters
Hardness, H
35-115 HRВ 10/40
Specific electrical resistance, p
31-57 μΩ·m
Current density, j
0,12 A/mm²
Transitional voltage drop on a pair of brushes, ΔUᵦ
2,7 V
Brush pressure, p
20-40 kPa
Circum velocity, Vₚₑᵣ
50 m/s
Friction factor, μ
0,25
Application area
Электродвигатели ДК408В, ДК410Р мотор-компрессоров вагонов метрополитена
Manufacturer country
Bulgaria
