DC motor MP225M

  • Brand: GAMA MOTORS
  • Product Code: MP225M
  • Availability: Pre-order 30 calendar days
7 050.00€
Main specifications
All specifications
Field current (If), А: 8.5
Rated power, кW: 55
Rated torque (M), Nm: 876
Rated speed (Nnom), rpm: 600
Max. speed (Nmax), rpm: 2500
Armature voltage (Ua), V: 400

DC motor MP225M power of 55 kW for the drive of the main movements in machine tools and other industrial machinery.

The engine is designed in accordance with current standards and complies with the requirements and standards of IEC 72-1, IEC 34-1, IEC38, ISO2373.

The electric motor of the main movement MP225M 55 kW is made with an integrated tachogenerator MT-6 4V/1000 min-1 and a forced cooling fan unit. Thermal protection is implemented using a posistor type B59155M130A70 manufactured by «SIEMENS»‎, which is triggered when a temperature of 130°C is reached.

In the serial production MP225M electric motor, electrographic brushes of the ЕG74 grade 8x16x32 mm are used. (8 pcs.).

Characteristic features MP225M:

  • magnetic laminations;
  • forced cooling using a fan, when the degree of protection IP23;
  • built-in thermal protection sensor;
  • built-in tachogenerator MT-6 (brush brand Е43 3.2х3.2х10 mm. (4 pcs.))
  • rated power up to maximum speed;
  • high reliability and durability.
Main characteristics
Field current (If), А 8.5
Rated power, кW 55
Rated torque (M), Nm 876
Rated speed (Nnom), rpm 600
Max. speed (Nmax), rpm 2500
Armature voltage (Ua), V 400
Additional characteristics
Field voltage (Uf), V 180
Nett weight (G), kg 764
Rotor intertia (J), kgm0 1.840
Armature current (Ia), А 165
Degree of protection, ІР 23
Class thermal insulation F
Manufacturer country Bulgaria
Warranty, month 12
