- Name: Asynchronous electric motor KBE 3001-4
- Brand: BALKANSKO ECHO
- Product Code: KBE_3001_4
- Availability: Pre-order 39 calendar days
0.00€
Main specifications
All specifications
Input voltage type :
AC
Input voltage, U :
380/220 V Y/Δ
Quantity phases:
3
Frequency, f :
50 Hz
Power electric, Рₑₗ :
7.5 kW
Speed of revolution nominal, Nₙₒₘ :
1380 rpm
Mode of operation:
S4
Constructive performance:
ІМ В5, ІМ V1, ІМ V3
Installation method:
ІМ 3001, ІМ 3011, ІМ 3031
Explosion protection:
missing
Brake:
present
Terms of agreement
All goods are certified
Privacy Policy
We accept payment online
Asynchronous electric motor KBE 3001-4
Specifications
Main characteristics
Input voltage type
AC
Input voltage, U
380/220 V Y/Δ
Quantity phases
3
Frequency, f
50 Hz
Power electric, Рₑₗ
7.5 kW
Speed of revolution nominal, Nₙₒₘ
1380 rpm
Mode of operation
S4
Constructive performance
ІМ В5, ІМ V1, ІМ V3
Installation method
ІМ 3001, ІМ 3011, ІМ 3031
Explosion protection
missing
Brake
present
Additional parameters
Maximum torque, Mₘₐₓ
105 Nm
Current, І
17 А
Oper. Regime
40 %
Number of poles
4
Start/h.
240 H⁻¹
Class thermal insulation
F
Braking torque, Mᵦ
100 Nm
Degree of protection
IP 54/22
Warranty
36 months
Mass, m
82 kg
Application area
Main lifting mechanism of rope hoists of VAT type
Manufacturer country
Bulgaria
