- Brand: BALKANSKO ECHO
- Product Code: KGE_3317-30_6
- Availability: Pre-order 39 calendar days
0 грн.
Main specifications
All specifications
Input voltage type :
AC
Input voltage, U :
380 V
Quantity phases:
3
Frequency, f :
50 Hz
Electric power, Р₁ :
1,5 kW
Electric power, Р₂ :
8 kW
Speed, N₁ :
170 rpm
Speed, N₂ :
940 rpm
Mode of operation:
S4
Constructive performance:
ІМ В5, ІМ V1, ІМ V3
Installation method:
ІМ 3001, ІМ 3011, ІМ 3031
Explosion protection:
missing
Terms of agreement
All goods are certified
Privacy Policy
We accept payment online
Asynchronous electric motor КГЕ 3317-30/6
Specifications
Main characteristics
Input voltage type
AC
Input voltage, U
380 V
Quantity phases
3
Frequency, f
50 Hz
Electric power, Р₁
1,5 kW
Electric power, Р₂
8 kW
Speed, N₁
170 rpm
Speed, N₂
940 rpm
Mode of operation
S4
Constructive performance
ІМ В5, ІМ V1, ІМ V3
Installation method
ІМ 3001, ІМ 3011, ІМ 3031
Explosion protection
missing
Additional parameters
Torgue starting/maximum, М₁max
140 Nm
Torgue starting/maximum, М₂max
140 Nm
Current, I₁
30 A
Current, I₂
19 A
Oper. Regime₁
10 %
Oper. Regime₂
40 %
Number of poles
6, 30
Start/h.
240 H⁻¹
Class thermal insulation
F
Braking torque, Mᵦ
125 Nm
Degree of protection
IP 54
Warranty
36 months
Mass, m
201 kg
Application area
Main lifting mechanism of rope hoists series T
Manufacturer country
Bulgaria
