- Brand: MMOTORS JSC
- Product Code: MA_112M-4_2
- Availability: Pre-order 39 calendar days
1 182.58€
Main specifications
All specifications
Input voltage type :
AC
Input voltage, U :
400/230 V Y/Δ
Quantity phases:
3
Frequency, f :
50 Hz
Electric power, Р₁ :
3,2 kW
Mechanical power, Р₁ :
4 hp
Electric power, Р₂ :
4,3 kW
Mechanical power, Р₂ :
5,5 hp
Speed, N₁ :
1425 rpm
Speed, N₂ :
2845 rpm
Axle height, H :
112 mm
Mode of operation:
S4
Constructive performance:
ІМ В3, ІМ В5, ІМ В6, ІМ В7, ІМ В8, ІМ В14, ІМ V1, ІМ V3, ІМ V5, ІМ V6, ІМ V18, ІМ V19
Installation method:
ІМ 1001, ІМ 1002, ІМ 1011, ІМ 1012, ІМ 1031, ІМ 1032, ІМ 1051, ІМ 1052, ІМ 1061, ІМ 1062, ІМ 1071, ІМ 1072, ІМ 3001, ІМ 3002, ІМ 3011, ІМ 3012, ІМ 3031, ІМ 3032, ІМ 3601, ІМ 3602, ІМ 3611, ІМ 3612, ІМ 3631, ІМ 3632
Explosion protection:
missing
Terms of agreement
All goods are certified
Privacy Policy
We accept payment online
Asynchronous electric motor MA 112M-4/2 is shipped from the territory of Bulgaria and Ukraine throughout the WORLD
Specifications
Main characteristics
Input voltage type
AC
Input voltage, U
400/230 V Y/Δ
Quantity phases
3
Frequency, f
50 Hz
Electric power, Р₁
3,2 kW
Mechanical power, Р₁
4 hp
Electric power, Р₂
4,3 kW
Mechanical power, Р₂
5,5 hp
Speed, N₁
1425 rpm
Speed, N₂
2845 rpm
Axle height, H
112 mm
Mode of operation
S4
Constructive performance
ІМ В3, ІМ В5, ІМ В6, ІМ В7, ІМ В8, ІМ В14, ІМ V1, ІМ V3, ІМ V5, ІМ V6, ІМ V18, ІМ V19
Installation method
ІМ 1001, ІМ 1002, ІМ 1011, ІМ 1012, ІМ 1031, ІМ 1032, ІМ 1051, ІМ 1052, ІМ 1061, ІМ 1062, ІМ 1071, ІМ 1072, ІМ 3001, ІМ 3002, ІМ 3011, ІМ 3012, ІМ 3031, ІМ 3032, ІМ 3601, ІМ 3602, ІМ 3611, ІМ 3612, ІМ 3631, ІМ 3632
Explosion protection
missing
Additional parameters
Current, I₁
7,7 A
Current, I₂
8,6 A
Number of poles
2, 4
PF
0.83/0.93
ETA
79/79 %
Class thermal insulation
F
Braking torque, Mᵦ
40 Nm
Degree of protection
IP 54/55
Warranty
18 months
Manufacturer country
Bulgaria
