- Name: Asynchronous electric motor MAL 132MCa-6B
- Brand: MMOTORS JSC
- Product Code: MAL_132MCa-6B
- Availability: Pre-order 39 calendar days
0.00€
Main specifications
All specifications
Input voltage type :
AC
Frequency, f :
50 Hz
Power electric, Рₑₗ :
8.0 kW
Power mechanical, Pₘ :
10.7 hp
Speed of revolution nominal, Nₙₒₘ :
930 rpm
Axle height, H :
132 mm
Mode of operation:
S4
Explosion protection:
missing
Brake:
present
Terms of agreement
All goods are certified
Privacy Policy
We accept payment online
Asynchronous electric motor MAL 132MCa-6B is shipped from the territory of Bulgaria and Ukraine throughout the WORLD
Specifications
Main characteristics
Input voltage type
AC
Frequency, f
50 Hz
Power electric, Рₑₗ
8.0 kW
Power mechanical, Pₘ
10.7 hp
Speed of revolution nominal, Nₙₒₘ
930 rpm
Axle height, H
132 mm
Mode of operation
S4
Explosion protection
missing
Brake
present
Additional parameters
Maximum torque, Mₘₐₓ
100 Nm
Current, І
20 А
Oper. Regime
40 %
Number of poles
6
Start/h.
240 H⁻¹
Class thermal insulation
F
Braking torque, Mᵦ
100.0-200.0 Nm
Degree of protection
IP 54
Warranty
18 months
Mass, m
86 kg
Application area
The main lift of electric lifts
Manufacturer country
Bulgaria
